Description
- ENGINE
- MakeKubota
- Maximum torque4 ft-lbs @ 1800-2200 rpm (5.6 kg-m @ 30.0-36.7 r/s)
- ModelD902-E4-UV1
- Type3-Cylinder, 4-cycle, Diesel, OHV
- CoolingWater-Cooled
- CARGO BOX
- Length5 in. (1030 mm)
- ENGINE
- Number of cycles4-Cycle
- Cylinders3-Cylinder
- Bore and stroke83 x 2.90 in. (72 x 73.6 mm)
- Displacement8 cu. in. (898 cc)
- Horsepower
- Engine gross @ rpm 21.6 Hp (16.1 kw) @ 3200 rpm
- Engine net @ rpm 20.6 Hp (15.4 kw) @ 3200 rpm
- LubricationForced lubrication
- Cooling systemLiquid Cooled w/ Pressurized Radiator
- Exhaust/mufflerMuffler with screen-type spark arrestor
- Air filterPaper filter w/ Safety Element
- Oil filterReplaceable Treated Paper Element
- COOLING SYSTEM
- TypeLiquid Cooled w/ Pressurized Radiator
- FUEL SYSTEM
- Fuel typeDiesel
- FLUID CAPACITIES
- Fuel tank capacity9 gals. (30 l)
- Cooling system capacity2 qts (4.0 l)
- Engine lubricant oil capacity3 qts (3.1 l)
- Transmission oil capacity6 gals. (10 l)
- Brake system capacity4 qts. (0.40 l) – DOT 3 Brake Fluid
